We Have The Best Solutions for Your Business
Guangxi CORERAY Optical Communication Technology Co.,Ltd. is an enterprise specializing in the production of passive components for optical communication.The company is committed to the large-scale application of laser communication passive device manufacturing technology.
We mainly provide Mechanical Optical Switch, Solid State Optical Switch, Large Port Optical Switch, Small Optical Switch, Optical Switch, Optical Filter, Mems Optical Switch, etc.
The role of optical switches in optical networks
Optical switches play a very important role in optical networks. In wavelength division multiplexing (WDM) transmission systems, optical switches can be used for wavelength adaptation, regeneration, and clock extraction. In Division Multiplex, (OTDM) systems, optical switches can be used for demultiplexing; in all-optical switching systems, optical switches are key components of Optical Cross-connect (OXC) and an important component of wavelength conversion.
1x128 optical switch Supplier
1x128 optical switch module is a functional component with the ability to switch optical routes. 1x128 optical mechanical optical switch is composed of one input and 128 output optical fiber ports, which can selectively transmit, redirect or block the optical power in the optical fiber transmission line. These all-optical switches are bidirectional and can be used in 1x128 or 128x1 directions. Optical fiber switches are designed for optical fiber communication networks and measuring instruments.
Optical switch application
The scope of application mainly includes: protection switching system of optical network, light source control in optical fiber testing, real-time monitoring system of network performance, testing of optical components, switching core for building OXC equipment, optical add/drop multiplexing, optical testing, optical transmission sensory system, etc.
Number of optical switch ports
According to the number of input and output ports of the optical switch, it can be divided into 1×1, 1×2, 1×N, 2×2, 2×N, M×N, etc., and they have different uses in different occasions.
Frequently Asked Question
Do you have any question?
Optical switches use light sensing to trigger switches. It works with a mechanical switch to block the light beam. When the switch is pressed, the switch lever moves downward to trigger the light sensor on the PCB and activate the key.
It is superior to optical switch in technology. They have longer service life and faster response time.
